Paging System

TOA Electronics, Inc. is dedicated to the development, manufacturing, and distribution of premier commercial audio and security products. TOA Corporation was founded in Kobe, Japan over 75 years ago. TOA operates in over 100 countries worldwide, with manufacturing facilities found in nearly every major market area. These facilities have a reputation for precision design and fabrication, resulting in a proven track record of TOA product reliability

Toa Paging System

ITC Paging System

Mixer / Amplifier

BG-2035 BG-2060 BG-2120

The BG-2000 Series Mixer/Amplifier consists of three models:BG-2035 (35W), BG-2060 (60W), BG-2120 (120W). They are a total redesign of the highly successful BG-1000 Series and not just for design’s sake. We spoke with our customers, who told us exactly what they wanted in a commercial background music & paging amplifier. We responded with a newly-engineered chassis, designed to not only look better, but perform better and most of all-install easier. Starting with removable euro-block connectors to make wiring a snap, we added assignable MOH/Second Zone source assignment and provided access to mute priority and other settings via rear panel DIP switches - no more “popping the top”. Lastly, we’ve upped the power to 35W on the lower end model. Of course, we kept all the good stuff-solid, reliable performance for which TOA has been renowned.

The BG-2000 Series Mixer/Amplifiers are UL/cUL approved, competitively priced and is backed by TOA's 5 year warranty.

Product Features

  • Compact five channel Mixer-Amplifier for paging, background/foreground music distribution and music/messaging-on-hold.
  • All inputs/outputs with removable terminal blocks allow quick and easy installation.
  • Any of five inputs assignable to MOH/ZONE 2 output.
  • RCA pin jacks for LINES 2 & 3.
  • Phantom Power (+ 24V DC) incorporated for MIC input.
  • Module slot accepts 900 Series plug-in input modules for custom system configurations. 900 Series output and equalizer modules are incompatible. For more information please call our Product Support Group.
  • Rear panel-mounted DIP switches allow easy configuring of settings.
  • Provides auto/manual mute function with adjustable muting sensitivity.
  • Incorporates Remote volume control connection.Optional TOA control AT-10K
  • 2-channel broadcast capability together with zone 2 expansion capability in conjunction with BA-200 Series.
  • Tamper-proof, front-panel bass and treble controls are recessed to protect their settings.
  • Thermal protection circuitry prevents potential damage from excessive heat build-up.
  • AC Mains Circuit Breaker.
  • Supplied accessory security knobs for volume controls prevent unauthorized volume setting changes.
  • Optional rack-mount kit.
  • UL/cUL Listed.
  • Five Year Warranty.

Ceiling Speaker

PC-580RU PC-580RVU

The PC-580RU & PC-580RVU are designed to fill the need for a high-performance / low-cost  ceiling speaker for paging and notification applications, especially  where retrofit of speakers in large facilities dictate that a common  speaker template is used, eliminating the need for adapting existing ceiling cutouts. The PC-580RU & PC-580RVU (along with the HY-BC580 AM  Back can) meet UL requirements for speakers used in emergency signaling  and notification applications.

Product Features

  • 8" in-Ceiling Speaker for high-quality paging applications
  • Low-cost design makes it ideal for projects requiring large quantities
  • 25 & 70V transformer taps up to 5W
  • Fits standard ceiling-speaker template (PC-671R and others). Perfect for retrofits
  • UL 1480 (UUMW) & UL 2043-rated. Certified to work with emergency announcement systems
  • Unique "monocoque" design provides better structural integrity
  • PC-580RVU version provides a center-grille volume adjustment potentiometer
  • Optional UL-rated HY-BC580 AM stackable back-can for use in ceiling plenums
  • Sold in quantities of 10

Remote Microphone Station

N-8610RM

The N-8610RM Remote Master Station is an IP remote microphone station that employs packet audio technology. High quality voice output is broadcast to N-8000 intercom door and master stations or to paging amplifiers using one of the IP to analog audio outputs available on the N-8000AF, N-8000MI or N-8000EX. 14 pre-programmed buttons provide access to stations, paging zones, one-touch dialing, 10-key and Function key. The N-8610RM may be expanded to 54 buttons using multiple RM-210 Extensions. The N-8610RM may be powered by PoE or an optional AD-1215 power supply. When using PoE with RM-210s, make sure that the available PoE can accommodate a minimum of 7.5 W on one port


Product Features

  • Employs packet audio technology
  • Connect to a LAN or WAN network
  • Power can supplied to the microphone using a PoE-compatible switching hub

Descriptions


The T-218(A) is a high performance remote zone paging console that works with zone paging controller T-6212(A) for remote paging and control over a multi-zone system.


Several paging modes (all zone, group zones, 10 zones and individual zones) could be achieved through this paging console. Features include capability of 16 microphones and 300 paging zones work at the same time, the T-218(A) will easily distinguish T-6212(A) with its pre-set ID address. T-218(A)'s paging system with priority over background music system.




Feature


* With operation number input keys and LED display


* Capacity of manage 30 paging selectors T-6212(A), up to 300 zones


* Max remote control distance up to 1Km


* With microphone volume control


* RCA line input and output


* Built-in chime and chime volume control


* Max 16 microphone work together with RJ45 port in series connection

Descriptions

1.4 channel Mic. inputs, 2 channel line inputs, separated treble and bass control.

2.6-channel zone output, zone volume is independently controlled.

3.Built-in bell, the bell tone is optional, 4 tones and 2 tones (built-in), the alarm generator.

4. MP3 decoder module supports USB / SD / Bluetooth / FM radio playback. Configuring MP3 remote control, support memory function without power input, MIC recording function.

5. When start the built-in generator, the background will turn off and 6-channel zone output will automatically turn on, switch to maximum output volume function.

6. Built-in 24V DC power input

7. MIC1- 4 built-in 48V phantom power and independent control switch.

8. T-216 remote microphone can remote control zone output, the maximum cascade 6pcs Mic.

9. The audio input with separate control, tone control and master volume control

10. A variety of LED display (signal, clip, protection LED indicator)

11. With fan forced cooling structure, to ensure the device to keep long time working
12. There are five priority levels:
EMC with top priority: When there is EMC alarm signal input, it overrides all audio, 6 zone outputs open automatically.
The 2nd priority level: TEL / REM MIC is priority to MIC1-4, LINE1-2,chime.The 3rd priority level: built-in alarm generator is priority toMIC1-4, LINE1-2, 6 zone outputs open automatically.

The 4th priority level :built-in chime is priority to MIC1-4, LINE1-2.
The 5th priority level :built MIC1 is priority to  MIC2-4, LINE1-2.
13. The constant voltage output: 70V, 100V, constant impedance output: 4-16Ω

Model



TI-1206S

TI-2406S

TI-3506S

Amplifier SectionLoad 100V Output)

Rated Output Power (THD 1%)

120W(RMS)

240W(RMS)

350W(RMS)

Speaker Zone 1~5 Output

25W MAX

50W MAX

70W MAX





Mic Input Section(Mic 1~4 In@1KHz)

Input Sensitivity/Impedance

5mV 600Ω/350mV 10KΩ BAL

S/N Ratio

Better than 75dB

Frequency Response (±3dB)

80Hz~16KHz

Tone Control (Bass:100Hz, Treble:10KHz)

±10dB

Phantom Power

+ 48V







Line Input Section

(Mic 1~2 In@1KHz)



Input Sensitivity/Impedance

350mV/47KΩ

S/N

Better than 80dB

Frequency Response (±3dB)

80Hz~16KHz

Tone Control (Bass: 100Hz,Treble:10KHz)

±10dB





Tel Audio Input



Input Sensitivity/Impedance

0.775V/10KΩ

S/N

Better than 75dB

Frequency Response (±3dB)

50Hz~16KHz





EMC Audio Input



Input Sensitivity/Impedance

0.775V/10KΩ

S/N

Better than 75dB

Frequency Response (±3dB)

80Hz~16KHz

Pre Amp Out(Mic 1~4, Line 1~2, Tel In, Remote In)

1V/600Ω

Remote MIC Sensitivity/Impedance

775mV/10KΩ

THD

Less than 0.1% at 1KHz, 1/3 rated power

Power Supply

~110V/60Hz or ~230V/50Hz & DC 24V

Power Consumption

180W

320W

500W

Weight

6.5Kg

7.1Kg

7.8Kg

Dimensions

484x310x88 mm


Features

  • Built-in 100v/70v transformer
  • In-ceiling type loudspeaker
  • 5” speaker unit
  • Power taps 1.5W, 3W & 6W @100V
  • Aluminum grille & metal baffle
  • Metal back box could be added



Description

The T-105 is a ceiling speaker built-in 70v/100v transformer. The 70v/100v transformer technique reduces line losses on longer distance and allows easy parallel connection of multiple loudspeakers.



The built-in 5” speaker driver is designed of wide frequency response 110-14.5kHz, the multiple power taps 1.5W, 3W & 6W are helpful for different applications varies from room size and ambient noise surroundings. The aluminum grille and metal baffle are painted in attractive white color. Its spring clip clamp makes the easy and secure installation.



It is ideal choice for industrial and commercial applications in hotel, school, office and factory where background music and paging is needed.

Specifications

Model

T-105

Power Taps @100V

1.5W, 3W, 6W

Power Taps @70V

0.75W, 1.5W, 3W

Impedance

Black: Com Red:6.7 KΩ Green:3.3KΩ White:1.7KΩ

SPL(1W/1M)

92dB

Max. SPL (Rated W/1M)

102dB

Frequency Response (-10dB)

110-14.5KHz

Finish

Baffle: Steel ,white   Grille: Steel , white

Speaker Driver

5" x 1

Cutout Size

170mm

Dimensions

200 x 55mm

Weight

0.8Kg

Mounting

Spring-clip
